Garmin Acc,Xdcr,CM599LHW,CHIRP,2kW/3kW,Cavity mount
Sutaupykite 5%
Garmin Acc,Xdcr,CM599LHW,CHIRP,2kW/3kW,Cavity mount, 010-12188-20 - prekės aprašymas
This pocket mounted transducer uses very narrow beams and low frequencies and wide beams for high frequencies to send depth and temperature to your Garmin Marine Network.
A pocket version of the R599LH, this 1 to 3 kW bare wire plastic transducer has a maximum depth of 10,000 feet; an operating frequency of 28 to 60 kHz and 150 to 250 kHz; and a beamwidth of 9x23 degrees or a constant 25 degrees. The pocket mount is installation dependent.
Transducer kit comes with installation instructions. Follow the instructions carefully to avoid damaging your boat.
Bendra |
|
| DAŽNIS | CHIRP Low (28-60 kHz) & CHIRP High Wide (150-250 kHz) |
|---|---|
| GALIA | 1 kW/3 kW |
| SPINDULIO PLOTIS | 5°x9°-11°x23°/24°-26° |
| MAKSIMALUS GYLIS | 10,000 ft. |
| LAIDO ILGIS | 70 ft. |
| GYLIS / GREITIS / TEMPERATŪRA | Depth and Temperature |
| ADATĖLIŲ SKAIČIUS | Bare wires |
| PALAIKOMAS KYLIO / TRANCO KAMPŲ NUSTATYMAS | Installation Dependent |
Nėra atsiliepimų
