5G/4G Maršrutizatorius Zyxel Nebula FWA510 (FWA510-EUZNN1F)

IP networking

• Supports IPv4/IPv6 dual stack (NDP IPv6)
• DHCP server
• Virtual Private Network (VPN) pass-through
• Supports NAT/NAPT
• Supports DMZ
• Multiple APNs
• Supports port forwarding
• Supports ALG

Routing

• Supports bridge and router modes
• Supports dynamic DNS for first APN
• Supports remote management under bridge mode
• Static/dynamic routing settings for RIP v1/v2

IP firewall

• DoS attack detection
• Supports SPI (Stateful Packet Inspection)
• Application-level firewall (LAN to WAN such as HTTP, Telnet, Ping)
• Filters LAN MAC address
• Filters LAN IP address
• Filters URLs

Management

• Supports local/remote device management and firmware upgrade via Nebula Cloud and web GUI
• SMS management
• PIN/PUK manage ment
• APN management
• Operating frequency band selection
• Supports Zyxel Air app (iOS and Android) for easy installation and local management only

WLAN feature

• Auto channel selection
• WiFi Protected Setup (WPS)
• WiFi Multimedia (WMM)
• WiFi-enabled devices: up to 64
• Security: none, WPA2-Personal, WPA+WPA2, WPA2+WPA3, WPA3
• MAC address filtering with 64 address supported
• Multiple SSIDs/hide SSIDs
• WLAN scheduling

5G NR interface

3GPP Release 15 standard-compliant

Supports both NSA and SA modes

Supports Sub-6 NR DL 2xCA (TDD/FDD)

Supports frequencies:

FDD: n1, n3, n5, n7, n8, n20, n28

TDD: n38, n40, n41, n77, n78

Supports DL 4×4 MIMO:

FDD: n1, n3, n5, n7

TDD: n38, n40, n41, n77, n78

Data rates:

5G SA: DL 4.67 Gbps*; UL: 2.5 Gbps*

5G NSA: DL 3.74 Gbps*; UL: 1.46 Gbps*

Output power:

Class 2 (26 dBm) for 5G NR n41/n78

Class 3 (23 dBm) for all 5G NR bands

4G LTE interface

3GPP UE Category 19 standard-compliant

Supports frequencies:

LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32

LTE-TDD: B38/B40/B41/B42

Supports DL 4×4 MIMO:

LTE-FDD: B1/B3/B7

LTE-TDD: B38/B40/B41/B42

Peak data rates:

Max. DL 1.6 Gbps/UL 200 Mbps**

Supports DL modulation QPSK, 16-QAM, 64-QAM and 256-QAM

Supports UL modulation QPSK, 16-QAM, 64-QAM and 256-QAM

Output power:

Class 2 (26 dBm) for LTE B41

Class 3 (23 dBm) for FDD/TDD LTE bands

WiFi air interface

Wireless standard:

IEEE 802.11 b/g/n/a/ac/ax

Wireless speeds:

Link rates up to 1.2 Gbps** for 2.4 GHz

Link rates up to 2.4 Gbps** for 5 GHz

WiFi antenna gain:

~3 dBi for 2.4 GHz

~5 dBi for 5 GHz

5G NR/4G LTE antennas

Four TS9 connectors for external antennas***

Four embedded omni-directional antennas

Ultra-high band:

Up to 5 dBi peak gain

High band and middle band:

Up to 5 dBi peak gain

Low band:

Up to 4 dBi peak gain

Hardware interface

Two 100/1000/2500 Mbps Ethernet RJ-45 LAN ports, LAN2 can be configured for Ethernet WAN port

LED indicators:

Power indication

SMS status

Signal strength

Internet connection status

Radio access technology status

WiFi AP status

WPS status

Four external antenna connectors (TS9 type)***

One 3FF/Micro SIM card slot

One power on/off button

One WPS/WiFi on/off button

One reset button

One Int/Ext antenna switch

One USB 3.0 host port for file sharing

48 W (peak)

Item

• dimensions (WxDxH):
  132.5 x 134 x 230 mm (5.22” x 5.28” x 9.06”)
• weight:
  1,006 g (2.22 lb.)

Packing

• dimensions (WxDxH):
  250 x 200 x 140 mm (9.84” x 7.87” x 5.51”)
• weight:
  1,504 g (3.32 lb.)

Operating Environment

• Temperature:
  0°C to 40°C (32°F to 104°F)
• Humidity:
  10% to 90% (non-condensing) Storage Environment

Storage Environment

• Temperature:
  -30°C to 70°C (-22°F to 158°F)
• Humidity:
  5% to 95% (non-condensing)

CE/Safety

WEEE (Waste Electrical and Electronic Equipment) Directive certification

RoHS (Restriction of Hazardous Substances) Directive certification

HSF (Hazardous Substance Free)

European Parliament and Council

Directive 94/62/EC of December 20, 1994 on packaging and packaging waste

EU/UK power adaptor

Ethernet cable 1.8 m 8P8C

Quick start guide

Warranty card

DoC

Safety warranty
